Also available in Hump-Reducer Design
Cold side (800C)
SHORE-FLEXTM 800 SERIES
CHARGE-AIR-COOLER HOSES
(COLD SIDE)
Silicone with multiple layers of polyester reinforcement- Working pressure is approximately 1/3rd of burst pressure
- Thickness: 3 +/- 0.5mm (excluding overlap)
- Suitable for extremely harsh temperatures: -56 to +180 deg C (-68.8 to +356 deg F)
- Silicone Hoses COMPLIES with fire specification UL94HB
|
Sr. no. |
Part No. |
Inner Diameter |
Outer Diameter |
Length |
# of Convolutes (Humps) | # of SS Rings |
Max Working Pressure (PSI) |
Max Working Pressure (MPA) |
|||
|
mm |
in |
mm |
in |
mm |
in |
||||||
|
1 |
800C250-060 |
63.5 |
2.50 |
70 |
2.74 |
152.4 |
6.00 |
2 |
3 |
60 |
0.41 |
|
2 |
800C300-060 |
76.2 |
3.00 |
82 |
3.24 |
152.4 |
6.00 |
2 |
3 |
60 |
0.41 |
|
3 |
800C350-060 |
88.9 |
3.50 |
95 |
3.74 |
152.4 |
6.00 |
2 |
3 |
55 |
0.38 |
|
4 |
800C350-075 |
88.9 |
3.50 |
95 |
3.74 |
190.5 |
7.50 |
2 |
3 |
55 |
0.38 |
|
5 |
800C400-060 |
101.6 |
4.00 |
108 |
4.24 |
152.4 |
6.00 |
2 |
3 |
50 |
0.34 |
|
6 |
800C400-065 |
101.6 |
4.00 |
108 |
4.24 |
165.1 |
6.50 |
2 |
3 |
50 |
0.34 |
|
7 |
800C400-070 |
101.6 |
4.00 |
108 |
4.24 |
177.8 |
7.00 |
2 |
3 |
50 |
0.34 |
|
8 |
800C400-075 |
101.6 |
4.00 |
108 |
4.24 |
190.5 |
7.50 |
2 |
3 |
50 |
0.34 |
|
9 |
800C400-080 |
101.6 |
4.00 |
108 |
4.24 |
203.2 |
8.00 |
2 |
3 |
50 |
0.34 |
|
10 |
800C450-060 |
114.3 |
4.50 |
120 |
4.74 |
152.4 |
6.00 |
2 |
3 |
45 |
0.31 |
|
11 |
800C500-060 |
127.0 |
5.00 |
133 |
5.24 |
152.4 |
6.00 |
2 |
3 |
35 |
0.24 |
|
Sr. no. |
Part No. |
Inner Diameter |
Outer Diameter |
Length |
# of Convolutes (Humps) | # of SS Rings |
Max Working Pressure (PSI) |
Max Working Pressure (MPA) |
|||
|
mm |
in |
mm |
in |
mm |
in |
||||||
|
1 |
800C250-300 |
63.5 |
2.50 |
76.2 |
3.00 |
101.6 |
4.00 |
1 |
2 |
40 |
0.28 |
|
2 |
800C300-350 |
76.2 |
3.00 |
88.9 |
3.50 |
127 |
5.00 |
1 |
2 |
55 |
0.38 |
|
3 |
800C300-400 |
76.2 |
3.00 |
101.6 |
4.00 |
152.4 |
6.00 |
1 |
2 |
50 |
0.34 |
|
4 |
800C350-400 |
88.9 |
3.50 |
101.6 |
4.00 |
152.4 |
6.00 |
1 |
2 |
50 |
0.34 |
|
5 |
800C400-450 |
101.6 |
4.00 |
114.3 |
4.50 |
152.4 |
6.00 |
1 |
2 |
30 |
0.21 |
